CINCINNATI 340-20

1-USED CINCINNATI 340-20 TWIN GRIP CNC CENTERLESS GRINDER

REBUILT BY GOLD CROWN FEB. 1997 WITH SERVO INFEED.

STK: 104568

SN: 350520H74-0048

DATE OF MFG. 1974

========================================================

CATALOGUE SPECIFICATIONS:

Work Diameter Capacity Maximum (With New Wheel)........ 6"

Work Diameter Capacity Nominal......................... 1/2" to 3"

Grinding Wheel Diameter, Maximum....................... 24"

Grinding Wheel Diameter, Minimum....................... 16"

Grinding Wheel Width, Maximum.......................... 20"

Grinding Wheel Width, Minimum.......................... 1"

Grinding Wheel Hole Diameter........................... 12"

Regulating Wheel Diameter, Maximum..................... 14"

Regulating Wheel Diameter, Minimum..................... 10.25"

Regulating Wheel Width, Maximum........................ 20"

Regulating Wheel Width, Minimum........................ 1"

Regulating Wheel Hole Diameter......................... 6"

Regulating Wheel Speeds (Variable)..................... 11 - 300 RPM

Grinding Wheel Motor................................... 40 HP

Regulating Wheel Motor................................. 2 HP

Hydraulic System Motor................................. 2 HP

Electrics.............................................. 230/460/3/60

Approximate Machine Dimensions......................... 114" x 158"

Approximate Machine Height............................. 96"

Approximate Machine Weight............................. 28,000 LBS
