BMS CELLMATE BMCM15-48 VERTICAL TABLE UP BROACHING MACHINE DUAL STATION

BMS CELLMATE BMCM15-48 VERTICAL TABLE UP BROACHING MACHINE DUAL STATION

$19,500 (USD)

Location:Saginaw, MI

Available quantity:1

orCall 586-752-0090 Extension 1 for Sales

Description

1-USED BMS CELLMATE 15 TON X 48" STROKE VERTICAL TABLE UP BROACHING MACHINE

MODEL BMCM15-48 DUAL STATION

SERIAL NUMBER 1144-98

DATE OF MFG. 1998

STK#105178

==============================================

SPECIFICATIONS WHILE OBTAINED FROM SOURCES DEEMED RELIABLE ARE SUBJECT TO CHANGE WITHOUT NOTICE AND TO VERIFICATION BY BUYER:


MODEL BMCM15-48

CAPACITY 15 TONS

STROKE 48"

PULLING CAPACITY 30,000 LBS

MAX CUTTING SPEED 30 FPM

MAX RETURN SPEED 60FPM

COOLANT RESIVOIR CAPACITY 175 GALLONS

OIL RESIVOIR CAPACITY 200 GALLONS

MAIN MOTOR HP 40

APPROX. FLOOR SPACE 118" X 72"

APPROX HEIGHT 164"

APPROX WEIGHT 32,000 LBS


EQUIPPED WITH:

DUAL STATION

CHIP CONVEYOR

COOLANT SYSTEM

AUTO LOADER

EXTERNAL HYDRAULIC UNIT JLC CONTROLS PANEL

OPERATORS STATION THIS ITEM IS OFFERED FOR SALE SUBJECT TO PRIOR SALE AND BUYER'S UNCONDITIONAL ACCEPTANCE OF SELLERS TERMS AND CONDITIONS. RAB INDUSTRIES, INC.

Specifications

ManufacturerBMS
ModelBMCM15-54
Year1998
ConditionUsed
Serial Number1144-98
Stock Number105178
